PHOTO-SONICS AM500 PL MOUNT - 16mm High-speed Camera

Ground glass: Standard 16mm/Tv Safe or 1:85

Frame rates: 24/ 48/ 100/ 200/ 300/ 400/ 500 fps

Voltage: 28V DC

Film: 16mm negative double-perf stock (2R) The camera runs with regular stock on max speed.

Magazines: 2 Mags each 400ft (122m) load

Exposure times: The variable shutter, allow to control of the exposure time independent from the used frame rate.

Shutter: 160°/ 120°/ 90°/ 60°/ 45°/ 30°/ 22,5°/ 15°/ 7,5°

Footage counter: The AM500 is fitted with an indicator in each magazine

Run-up, Run-down: The camera requires very brief run-up and run-down times. The Run up to 500 fps lasts about 3 seconds, the run-down about 2 seconds. At lower frame rates, these times are shorter.

Reflex viewfinder: Continue reflex viewfinder. The viewfinder image is mirrored out by a beam splitter. This allows continual view during the take.

Light loss: The beam splitter takes about 1/2 stop.

Lenses: all Lenses with PL mount (with restrictions).

Video Assist: Video Assist: CEI colour V PAL video camera.
